固定电感器
| 图片 | 厂商型号 | 可用性 | 价格 | 数量 | 数据表 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 电感 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 屏蔽 | 直流电阻 (DCR) | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 额定值 | 工作温度 | 电感频率 - 测试 | 特性 | 安装类型 | 供应商设备封装 | 尺寸 / 尺寸 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
B82496C3121G000FIXED IND 120NH 160MA 3 OHM SMD |
4,591 | - |
|
数据表 |
SIMID | 0603 (1608 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ceramic | 120 nH | ±2% | 160 mA | - | Unshielded | 3Ohm Max | 5 @ 25.2MHz | 1.8GHz | AEC-Q200 | -55°C ~ 150°C | 25.2 MHz | - | Surface Mount | 0603 (1608 Metric) | 0.063" L x 0.031" W (1.60mm x 0.80mm) | 0.035" (0.90mm) |
|
SPM6550T-1R0M100AFIXED IND 1.09UH 14.1A 5.2 MOHM |
3,450 | - |
|
数据表 |
SPM | 2-SMD, J-Lead | Tape & Reel (TR) | Active | Drum Core, Wirewound | Metal | 1.09 µH | ±20% | 14.1 A | 15.3A | Shielded | 5.2mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.280" L x 0.256" W (7.10mm x 6.50mm) | 0.197" (5.00mm) |
|
CDH53NP-101JCFIXED IND 100UH 370MA 1.57OHM SM |
3,327 | - |
|
数据表 |
CDH53 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 100 µH | ±5% | 370 mA | - | Unshielded | 1.57Ohm Max | - | - | - | -40°C ~ 100°C | 1 kHz | - | Surface Mount | - | 0.236" L x 0.205" W (6.00mm x 5.20mm) | 0.126" (3.20mm) |
|
84105CFIXED IND 1MH 90MA 18 OHM SMD |
2,714 | - |
|
数据表 |
8400 | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 1 mH | ±10% | 90 mA | - | Unshielded | 18Ohm Max | - | - | - | -40°C ~ 125°C | - | - | Surface Mount | - | 0.177" L x 0.130" W (4.50mm x 3.30mm) | 0.114" (2.90mm) |
|
L04021R0BHNTRFIXED IND 1NH 500MA 150 MOHM SMD |
2,680 | - |
|
数据表 |
Accu-L® 0402 | 0402 (1005 Metric) | Tape & Reel (TR) | Active | Thin Film | Non-Magnetic | 1 nH | ±0.1nH | 500 mA | - | Unshielded | 150mOhm Max | 20 @ 450MHz | 20GHz | - | - | 450 MHz | - | Surface Mount | 0402 (1005 Metric) | 0.039" L x 0.023" W (1.00mm x 0.58mm) | 0.018" (0.45mm) |
|
|
84332CFIXED IND 3.3UH 1.5A 120MOHM SMD |
2,000 | - |
|
数据表 |
8400 | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 3.3 µH | ±20% | 1.5 A | - | Unshielded | 120mOhm Max | - | - | - | -40°C ~ 125°C | - | - | Surface Mount | - | 0.177" L x 0.130" W (4.50mm x 3.30mm) | 0.114" (2.90mm) |
|
VLS3012HBX-R33N-NINDUCTORS FOR POWER CIRCUITS, WO |
1,830 | - |
|
数据表 |
VLS-HBX | 1212 (3030 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Metal | 330 nH | ±30% | 6.1 A | 8.6A | Shielded | 30mOhm Max | - | - | - | -40°C ~ 105°C | 1 MHz | - | Surface Mount | 1212 | 0.118" L x 0.118" W (3.00mm x 3.00mm) | 0.047" (1.20mm) |
|
|
84222CFIXED IND 2.2UH 2A 90 MOHM SMD |
1,690 | - |
|
数据表 |
8400 | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 2.2 µH | ±20% | 2 A | - | Unshielded | 90mOhm Max | - | - | - | -40°C ~ 125°C | - | - | Surface Mount | - | 0.177" L x 0.130" W (4.50mm x 3.30mm) | 0.114" (2.90mm) |
|
|
L04021R2BHNTRFIXED IND 1.2NH 400MA 200MOHM SM |
1,159 | - |
|
数据表 |
Accu-L® 0402 | 0402 (1005 Metric) | Tape & Reel (TR) | Active | Thin Film | Non-Magnetic | 1.2 nH | ±0.1nH | 400 mA | - | Unshielded | 200mOhm Max | 20 @ 450MHz | 20GHz | - | - | 450 MHz | - | Surface Mount | 0402 (1005 Metric) | 0.039" L x 0.023" W (1.00mm x 0.58mm) | 0.018" (0.45mm) |
|
SDR0403-331KLFIXED IND 330UH 170MA 6 OHM SMD |
41,049 | - |
|
数据表 |
SDR0403 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 330 µH | ±10% | 170 mA | 250mA | Unshielded | 6Ohm Max | 40 @ 796kHz | 4MHz | - | -40°C ~ 125°C | 1 kHz | - | Surface Mount | - | 0.177" L x 0.157" W (4.50mm x 4.00mm) | 0.138" (3.50mm) |
|
SDR0302-820KLFIXED IND 82UH 280MA 2.1 OHM SMD |
37,335 | - |
|
数据表 |
SDR0302 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 82 µH | ±10% | 280 mA | 300mA | Unshielded | 2.1Ohm Max | 24 @ 2.52MHz | 12MHz | - | -40°C ~ 125°C | 1 kHz | - | Surface Mount | - | 0.118" L x 0.110" W (3.00mm x 2.80mm) | 0.110" (2.80mm) |
|
SDR0604-680KLFIXED IND 68UH 620MA 520MOHM SMD |
29,726 | - |
|
数据表 |
SDR0604 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 68 µH | ±10% | 620 mA | 840mA | Unshielded | 520mOhm Max | 22 @ 2.52MHz | 10MHz | - | -40°C ~ 125°C | 1 kHz | - | Surface Mount | - | 0.228" L x 0.228" W (5.80mm x 5.80mm) | 0.189" (4.80mm) |
|
|
SDR0604-4R7MLFIXED IND 4.7UH 1.8A 80 MOHM SMD |
18,040 | - |
|
数据表 |
SDR0604 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 4.7 µH | ±20% | 1.8 A | 3A | Unshielded | 80mOhm Max | 20 @ 7.96MHz | 34MHz | - | -40°C ~ 125°C | 1 kHz | - | Surface Mount | - | 0.228" L x 0.228" W (5.80mm x 5.80mm) | 0.189" (4.80mm) |
|
B82498F3101J001FIXED IND 100NH 450MA 280MOHM SM |
12,518 | - |
|
数据表 |
SIMID | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ceramic | 100 nH | ±5% | 450 mA | - | Unshielded | 280mOhm Max | 55 @ 500MHz | 1.35GHz | - | -55°C ~ 125°C | 150 MHz | - | Surface Mount | 0805 (2012 Metric) | 0.091" L x 0.067" W (2.30mm x 1.70mm) | 0.055" (1.40mm) |
|
BMCA000606304R7MD1FIXED IND 4.7UH 5.5A 40 MOHM SMD |
9,115 | - |
|
数据表 |
BMCA | Nonstandard | Tape & Reel (TR) | Active | Molded | - | 4.7 µH | ±20% | 5.5 A | 10A | Shielded | 40mOhm Max | - | - | - | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.274" L x 0.260" W (6.95mm x 6.60mm) | 0.118" (3.00mm) |
|
|
SDR0403-1R4MLFIXED IND 1.4UH 3.3A 38 MOHM SMD |
7,423 | - |
|
数据表 |
SDR0403 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 1.4 µH | ±20% | 3.3 A | 5.1A | Unshielded | 38mOhm Max | 28 @ 7.96MHz | 110MHz | - | -40°C ~ 125°C | 1 kHz | - | Surface Mount | - | 0.177" L x 0.157" W (4.50mm x 4.00mm) | 0.138" (3.50mm) |
|
SRN6045TA-1R2YFIXED IND 1.2UH 7.5A 10.5MOHM SM |
6,975 | - |
|
数据表 |
SRN6045TA | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 1.2 µH | ±30% | 7.5 A | 12.5A | Shielded | 10.5mOhm | 15 @ 1MHz | 90MHz | AEC-Q200 | -55°C ~ 125°C | 1 MHz | - | Surface Mount | - | 0.236" L x 0.236" W (6.00mm x 6.00mm) | 0.177" (4.50mm) |
|
|
SDR0604-121KLFIXED IND 120UH 480MA 930MOHM SM |
6,877 | - |
|
数据表 |
SDR0604 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 120 µH | ±10% | 480 mA | 600mA | Unshielded | 930mOhm Max | 22 @ 796kHz | 7MHz | - | -40°C ~ 125°C | 1 kHz | - | Surface Mount | - | 0.228" L x 0.228" W (5.80mm x 5.80mm) | 0.189" (4.80mm) |
|
VLCF5020T-3R3N2R0-1FIXED IND 3.3UH 2.02A 96MOHM SMD |
5,860 | - |
|
数据表 |
VLCF | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 3.3 µH | ±30% | 2.02 A | 2.02A | Shielded | 96mOhm Max | - | - | - | -40°C ~ 105°C | 100 kHz | - | Surface Mount | - | 0.197" L x 0.197" W (5.00mm x 5.00mm) | 0.079" (2.00mm) |
|
SDR0403-330KLFIXED IND 33UH 640MA 540MOHM SMD |
5,683 | - |
|
数据表 |
SDR0403 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 33 µH | ±10% | 640 mA | 990mA | Unshielded | 540mOhm Max | 23 @ 2.52MHz | 15MHz | - | -40°C ~ 125°C | 1 kHz | - | Surface Mount | - | 0.177" L x 0.157" W (4.50mm x 4.00mm) | 0.138" (3.50mm) |
