直流直流转换器（DC DC Converters）
| 图片 | 厂商型号 | 可用性 | 价格 | 数量 | 数据表 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 输出数量 | 电压 - 输入（最小） | 电压 - 输入（最大） | 电压 - 输出 1 | 电压 - 输出 2 | 电压 - 输出 3 | 电压 - 输出 4 | 电流 - 输出（最大值） | 功率（瓦特） | 电压 - 隔离 | 应用 | 特性 | 工作温度 | 效率 | 等级 | 认证 | 安装类型 | 尺寸 / 尺寸 | 供应商设备封装 | 控制特性 | 认证机构 | 标准编号 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
PUD-2415BSDC DC CONVERTER +/-15V 1W |
103 | - |
|
数据表 |
PU-S (1W) | 7-SIP Module, 5 Leads | Tube | Active | Isolated Module | 2 | 21.6V | 26.4V | 15V | -15V | - | - | 34mA, 34mA | 1 W | 3 kV | ITE (Commercial) | - | -40°C ~ 85°C | 80% | - | - | Through Hole | - | - | CE, FCC | - | |
|
|
1T8E_0312S1UISOLATED MODULE DC DC CONVERTERS |
250 | - |
|
数据表 |
1T8E_1U (1W) | 8-SMD Module, 5 Leads | Tape & Reel (TR) | Not For New Designs | Isolated Module | 1 | 2.97V | 3.63V | 12V | - | - | - | 84mA | 1 W | 1 kV | ITE (Commercial) | - | -40°C ~ 85°C (With Derating) | 78% | - | - | Surface Mount | - | - | - | - | |
|
PDS1-S24-S5-MDC DC CONVERTER 5V 1W |
333 | - |
|
数据表 |
PDS1-M (1W) | 8-SMD Module, 5 Leads | Tube | Obsolete | Isolated Module | 1 | 21.6V | 26.4V | 5V | - | - | - | 200mA | 1 W | 1.5 kV | ITE (Commercial) | SCP | -40°C ~ 105°C (With Derating) | 80% | - | - | Surface Mount | - | - | EN, UL | 55024; 55032 Class A; 60950-1 | |
|
PRME1-S12-S5-M-TRDC-DC ISOLATED 3K, 1 W, 11.4~12. |
416 | - |
|
数据表 |
PRME1-M (1W) | 10-SMD Module, 6 Leads | Tape & Reel (TR) | Not For New Designs | Isolated Module | 1 | 11.4V | 12.6V | 5V | - | - | - | 200mA | 1 W | 3 kV | ITE (Commercial) | Adjustable Output | -40°C ~ 85°C (With Derating) | 69% | - | - | Surface Mount | - | - | CE | 62368-1 | |
|
|
VEFT1-S24-S5-SMT-TRDC DC CONVERTER 5V 1W |
0 | - |
|
数据表 |
VEFT1-SMT (1W) | 12-SMD Module, 10 Leads | Tape & Reel (TR) | Obsolete | Isolated Module | 1 | 21.6V | 26.4V | 5V | - | - | - | 200mA | 1 W | 3 kV | ITE (Commercial) | SCP | -40°C ~ 85°C | 79% | - | - | Surface Mount | - | - | - | - | |
|
PDSE2-S24-S5-M-TRDC-DC 1.5KV ISOLATED, 2 W, 21.6~ |
1,287 | - |
|
数据表 |
PDSE2-M (2W) | 8-SMD Module, 5 Leads | Tape & Reel (TR) | Not For New Designs | Isolated Module | 1 | 21.6V | 26.4V | 5V | - | - | - | 400mA | 2 W | 1.5 kV | ITE (Commercial) | Adjustable Output | -40°C ~ 105°C (With Derating) | 83% | - | - | Surface Mount | - | - | CE | 62368-1 | |
|
MDS02L-15DC DC CONVERTER 15V 2W |
871 | - |
|
数据表 |
MDS02 (2W) | 7-SIP Module, 4 Leads | Tube | Obsolete | Isolated Module | 1 | 4.5V | 5.5V | 15V | - | - | - | 133mA | 2 W | 6 kV | Medical | SCP | -40°C ~ 85°C | 79% | - | - | Through Hole | 7-SIP | - | - | - | |
|
UWE1212S-3WR3DC DC CONVERTER,3W,12VDC |
452 | - |
|
数据表 |
UWE_S-3WR3 (3W) | 8-SIP Module, 7 Leads | Tube | Not For New Designs | Isolated Module | 2 | 4.5V | 36V | 12V | -12V | - | - | 125mA, 125mA | 3 W | 3 kV | ITE (Commercial) | - | -40°C ~ 105°C (With Derating) | 79% | - | - | Through Hole | - | - | CE | - | |
Gull Wing12.7mm.jpg)
|
PES1-S5-S24-M-TRDC DC CONVERTER 24V 1W |
460 | - |
|
数据表 |
PES1-M (1W) | 8-SMD Module, 6 Leads | Tape & Reel (TR) | Obsolete | Isolated Module | 1 | 4.5V | 5.5V | 24V | - | - | - | 42mA | 1 W | 3 kV | ITE (Commercial) | SCP | -40°C ~ 105°C (With Derating) | 80% | - | - | Surface Mount | - | - | EN, UL | 55024; 55032 Class A; 60950-1 | |
|
VRB2405S-6WR3DC DC CONVERTER 5V 6W |
479 | - |
|
数据表 |
VRB2412S-6WR3 (6W) | 8-SIP Module, 7 Leads | Tube | Not For New Designs | Isolated Module | 1 | 18V | 36V | 5V | - | - | - | 1.2A | 6 W | 1.6 kV | ITE (Commercial) | - | -40°C ~ 105°C (With Derating) | 82% | - | - | Through Hole | - | - | CE, UKCA | 62368-1 | |
|
|
VRB1203S-6WR3DC DC CONVERTER 3.3V 6W |
252 | - |
|
数据表 |
VRB1203S-6WR3 (6W) | 8-SIP Module, 7 Leads | Tube | Not For New Designs | Isolated Module | 1 | 9V | 18V | 3.3V | - | - | - | 1.35A | 4.4 W | 1.6 kV | ITE (Commercial) | - | -40°C ~ 105°C (With Derating) | 76% | - | - | Through Hole | - | - | CE, UKCA | 62368-1 | |
|
|
WRB2412S-1WR2ISOLATED MODULE DC DC CONVERTER |
136 | - |
|
数据表 |
WRB_S-1WR2 (1W) | 8-SIP Module, 7 Leads | Tube | Not For New Designs | Isolated Module | 1 | 18V | 36V | 12V | - | - | - | 83mA | 1 W | 1.5 kV | ITE (Commercial) | Remote On/Off | -40°C ~ 85°C | 78% | - | - | Through Hole | - | - | CE | 62368-1 | |
|
|
VRB2403S-6WR3DC DC CONVERTER 3.3V 6W |
123 | - |
|
数据表 |
VRB2405S-6WR3 (6W) | 8-SIP Module, 7 Leads | Tube | Not For New Designs | Isolated Module | 1 | 18V | 36V | 3.3V | - | - | - | 1.35A | 4.4 W | 1.6 kV | ITE (Commercial) | - | -40°C ~ 105°C (With Derating) | 78% | - | - | Through Hole | - | - | CE, UKCA | 62368-1 | |
|
|
VRB1215S-6WR3DC DC CONVERTER 15V 6W |
102 | - |
|
数据表 |
VRB1215S-6WR3 (6W) | 8-SIP Module, 7 Leads | Tube | Not For New Designs | Isolated Module | 1 | 9V | 18V | 15V | - | - | - | 400mA | 6 W | 1.6 kV | ITE (Commercial) | - | -40°C ~ 105°C (With Derating) | 84% | - | - | Through Hole | - | - | CE, UKCA | 62368-1 | |
|
|
K12MT-16A-PNON-ISOLATED POL MODULE DC DC CO |
670 | - |
|
数据表 |
K12MT-16A | 17-SMD Module | Tape & Reel (TR) | Not For New Designs | Non-Isolated PoL Module | 1 | 4.5V | 14.4V | 0.6 ~ 3.63V | - | - | - | 16A | 58 W | - | ITE (Commercial) | Adjustable Output, Remote On/Off | -40°C ~ 85°C (With Derating) | 92% | - | - | Surface Mount | - | Enable, Active High | - | - | |
|
|
K12MT-16A-NNON-ISOLATED POL MODULE DC DC CO |
666 | - |
|
数据表 |
K12MT-16A | 17-SMD Module | Tape & Reel (TR) | Not For New Designs | Non-Isolated PoL Module | 1 | 4.5V | 14.4V | 0.6 ~ 3.63V | - | - | - | 16A | 58 W | - | ITE (Commercial) | Adjustable Output, Remote On/Off | -40°C ~ 85°C (With Derating) | 92% | - | - | Surface Mount | - | Enable, Active Low | - | - | |
|
R0.5S-1205DC DC CONVERTER 5V 500MW |
160 | - |
|
数据表 |
ECONOLINE R0.5S (0.5W) | 8-SMD Module, 5 Leads | Tube | Active | Isolated Module | 1 | 10.8V | 13.2V | 5V | - | - | - | 100mA | 500 mW | 1 kV | ITE (Commercial) | SCP | -40°C ~ 100°C | 74% | - | - | Surface Mount | - | - | - | - | |
|
PCN1-S12-D5-M-TRDC DC CONVERTER +/-5V 1W |
342 | - |
|
数据表 |
PCN1-M (1W) | 10-SMD Module, 5 Leads | Tape & Reel (TR) | Active | Isolated Module | 2 | 10.8V | 13.2V | 5V | -5V | - | - | 100mA, 100mA | 1 W | 1.5 kV | ITE (Commercial) | SCP | -40°C ~ 100°C | 77% | - | - | Surface Mount | - | - | EN | 55032 Class A | |
|
|
LMS78_15-1.0RDC-DC STEP DOWN REGULATORS |
135 | - |
|
数据表 |
LMS78_1.0R | 3-SIP Module | Tube | Active | Non-Isolated PoL Module | 1 | 8V | 36V | 15V or -15V | - | - | - | 1A or 300mA | 20 W | - | ITE (Commercial) | - | -40°C ~ 85°C (With Derating) | 96% | - | - | Through Hole | - | - | CE, cURus | 60950-1 | |
|
|
2T8A1_1205S3UPDC-DC INDUSTRIAL |
500 | - |
|
数据表 |
2T8A1_3UP (2W) | 8-SMD Module, 5 Leads | Tube | Obsolete | Isolated Module | 1 | 10.8V | 13.2V | 5V | - | - | - | 400mA | 2 W | 3 kV | ITE (Commercial) | - | -40°C ~ 105°C (With Derating) | 83% | - | - | Surface Mount | - | - | - | - |
