工业用 DIN 导轨电源
| 图片 | 厂商型号 | 可用性 | 价格 | 数量 | 数据表 | 系列 | 包装 | 产品状态 | 输入类型 | 输出数量 | 交流电压 - 输入 | 直流电压 - 输入（最小值） | 直流电压 - 输入（最大值） | 电压 - 输出 1 | 电压 - 输出 2 | 电压 - 输出 3 | 电压 - 输出 4 | 电压 - 输出 5 | 电压 - 输出 6 | 电流 - 输出（最大值） | 功率（瓦特） | 电压 - 隔离 | 应用 | 效率 | 工作温度 | 特性 | 尺寸 / 尺寸 | 认证机构 | 标准编号 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
56YSD15S-0502400AC/DC DIN RAIL SUPPLY 5V 12W |
698 | - |
|
数据表 |
56YSD15S (15W) | Box | Active | AC | 1 | 90 ~ 264 VAC | - | - | 5V | - | - | - | - | - | 2.4A | 12W | - | Industrial, ITE (Commercial) | 79% | -20°C ~ 50°C | Adjustable Output, IP20 | BSMI, CE, EAC, TUV, UL | 508; 60950-1 | |
|
HDR-15-5AC/DC DIN RAIL SUPPLY 5V 12W |
3,990 | - |
|
数据表 |
HDR-15 (15W) | Box | Active | AC or DC | 1 | 85 ~ 264 VAC | 120V | 370V | 5V | - | - | - | - | - | 2.4A | 12W | 4 kV | Industrial, ITE (Commercial) | 80% | -30°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | CB, CE, cULus, cURus, TUV | - | |
|
MDR-20-5AC/DC DIN RAIL SUPPLY 5V 15W |
0 | - |
|
数据表 |
MDR-20 (20W) | Box | Active | AC or DC | 1 | 85 ~ 264 VAC | 120V | 370V | 5V | - | - | - | - | - | 3A | 15W | 3 kV | Industrial, ITE (Commercial) | 76% | -20°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | CB, CE, cULus, TUV | - | |
|
|
HDR-15-24AC/DC DIN RAIL SUPPLY 24V 15W |
944 | - |
|
数据表 |
HDR-15 (15W) | Box | Active | AC or DC | 1 | 85 ~ 264 VAC | 120V | 370V | 24V | - | - | - | - | - | 630mA | 15W | 4 kV | Industrial, ITE (Commercial) | 86% | -30°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | CB, CE, cULus, cURus, TUV | - | |
|
1394764AC/DC DIN RAIL SUPPLY 24V 60W |
822 | - |
|
数据表 |
- | Box | Active | AC | 1 | 85 ~ 264 VAC | - | - | 24V | - | - | - | - | - | 2.5A | 60W | 4 kV | Laboratory | 89% | -20°C ~ 70°C (With Derating) | Adjustable Output, IP20, PFC, Universal Input | CB, UL | 61010-1 | |
|
DRC-24V10W1AZAC/DC DIN RAIL SUPPLY 24V 10W |
4,922 | - |
|
数据表 |
Chrome (10W) | Bulk | Active | AC | 1 | 90 ~ 264 VAC | - | - | 24V | - | - | - | - | - | 420mA | 10W | 3 kV | ITE (Commercial) | 80% | -25°C ~ 71°C (With Derating) | Adjustable Output, IP20, Universal Input | CB, CE, cULus, cURus, TUV | - | |
|
|
HDR-15-12AC/DC DIN RAIL SUPPLY 12V 15W |
2,581 | - |
|
数据表 |
HDR-15 (15W) | Box | Active | AC or DC | 1 | 85 ~ 264 VAC | 120V | 370V | 12V | - | - | - | - | - | 1.25A | 15W | 4 kV | Industrial, ITE (Commercial) | 85% | -30°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | CB, CE, cULus, cURus, TUV | - | |
|
|
MDR-20-24AC/DC DIN RAIL SUPPLY 24V 24W |
291 | - |
|
数据表 |
MDR-20 (20W) | Box | Active | AC or DC | 1 | 85 ~ 264 VAC | 120V | 370V | 24V | - | - | - | - | - | 1A | 24W | 3 kV | Industrial, ITE (Commercial) | 84% | -20°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | CB, CE, cULus, TUV | - | |
|
HDR-30-12AC/DC DIN RAIL SUPPLY 12V 24W |
676 | - |
|
数据表 |
HDR-30 (30W) | Box | Active | AC or DC | 1 | 85 ~ 264 VAC | 120V | 370V | 12V | - | - | - | - | - | 2A | 24W | 4 kV | Industrial, ITE (Commercial) | 88% | -30°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | CB, CE, cULus, cURus, TUV | - | |
|
|
HDR-30-24AC/DC DIN RAIL SUPPLY 24V 36W |
531 | - |
|
数据表 |
HDR-30 (30W) | Box | Active | AC or DC | 1 | 85 ~ 264 VAC | 120V | 370V | 24V | - | - | - | - | - | 1.5A | 36W | 4 kV | Industrial, ITE (Commercial) | 89% | -30°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | CB, CE, cULus, cURus, TUV | - | |
|
|
HDR-30-15AC/DC DIN RAIL SUPPLY 15V 30W |
167 | - |
|
数据表 |
HDR-30 (30W) | Box | Active | AC or DC | 1 | 85 ~ 264 VAC | 120V | 370V | 15V | - | - | - | - | - | 2A | 30W | 4 kV | Industrial, ITE (Commercial) | 89% | -30°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | CB, CE, cULus, cURus, TUV | - | |
|
DDR-15L-12DC/DC DIN RAIL SUPPLY 12V 15W |
1,895 | - |
|
数据表 |
DDR-15 (15W) | Box | Active | DC | 1 | - | 18V | 75V | 12V | - | - | - | - | - | 1.25A | 15W | 4 kV | ITE (Commercial) | 86% | -40°C ~ 85°C (With Derating) | Adjustable Output | CE, EAC | - | |
|
MDR-40-24AC/DC DIN RAIL SUPPLY 24V 41W |
253 | - |
|
数据表 |
MDR-40 (40W) | Box | Active | AC or DC | 1 | 85 ~ 264 VAC | 120V | 370V | 24V | - | - | - | - | - | 1.7A | 41W | 3 kV | Hazardous Locations, Industrial, ITE (Commercial) | 88% | -20°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | CB, CE, cULus, cURus, TUV | - | |
|
|
MDR-40-5AC/DC DIN RAIL SUPPLY 5V 30W |
128 | - |
|
数据表 |
MDR-40 (40W) | Box | Active | AC or DC | 1 | 85 ~ 264 VAC | 120V | 370V | 5V | - | - | - | - | - | 6A | 30W | 3 kV | Hazardous Locations, Industrial, ITE (Commercial) | 78% | -20°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | CB, CE, cULus, cURus, TUV | - | |
|
|
DDR-15G-12DC/DC DIN RAIL SUPPLY 12V 15W |
1,416 | - |
|
数据表 |
DDR-15 (15W) | Box | Active | DC | 1 | - | 9V | 36V | 12V | - | - | - | - | - | 1.25A | 15W | 4 kV | ITE (Commercial) | 85% | -40°C ~ 85°C (With Derating) | Adjustable Output | CE, EAC | - | |
|
HDR-60-24AC/DC DIN RAIL SUPPLY 24V 60W |
534 | - |
|
数据表 |
HDR-60 (60W) | Box | Active | AC or DC | 1 | 85 ~ 264 VAC | 120V | 370V | 24V | - | - | - | - | - | 2.5A | 60W | 4 kV | Industrial, ITE (Commercial) | 90% | -30°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | CB, CE, cULus, cURus, TUV | - | |
|
MDR-60-12AC/DC DIN RAIL SUPPLY 12V 60W |
444 | - |
|
数据表 |
MDR-60 (60W) | Box | Active | AC or DC | 1 | 85 ~ 264 VAC | 120V | 370V | 12V | - | - | - | - | - | 5A | 60W | 3 kV | Hazardous Locations, Industrial, ITE (Commercial) | 86% | -20°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | CB, CE, cULus, cURus, TUV | - | |
|
|
MDR-60-24AC/DC DIN RAIL SUPPLY 24V 60W |
723 | - |
|
数据表 |
MDR-60 (60W) | Box | Active | AC or DC | 1 | 85 ~ 264 VAC | 120V | 370V | 24V | - | - | - | - | - | 2.5A | 60W | 3 kV | Hazardous Locations, Industrial, ITE (Commercial) | 88% | -20°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | CB, CE, cULus, cURus, TUV | - | |
|
|
MDR-60-48AC/DC DIN RAIL SUPPLY 48V 60W |
224 | - |
|
数据表 |
MDR-60 (60W) | Box | Active | AC or DC | 1 | 85 ~ 264 VAC | 120V | 370V | 48V | - | - | - | - | - | 1.25A | 60W | 3 kV | Hazardous Locations, Industrial, ITE (Commercial) | 87% | -20°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | CB, CE, cULus, cURus, TUV | - | |
|
|
MDR-40-12AC/DC DIN RAIL SUPPLY 12V 40W |
1,736 | - |
|
数据表 |
MDR-40 (40W) | Box | Active | AC or DC | 1 | 85 ~ 264 VAC | 120V | 370V | 12V | - | - | - | - | - | 3.33A | 40W | 3 kV | Hazardous Locations, Industrial, ITE (Commercial) | 86% | -20°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | CB, CE, cULus, cURus, TUV | - |
