直流直流转换器（DC DC Converters）
| 图片 | 厂商型号 | 可用性 | 价格 | 数量 | 数据表 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 输出数量 | 电压 - 输入（最小） | 电压 - 输入（最大） | 电压 - 输出 1 | 电压 - 输出 2 | 电压 - 输出 3 | 电压 - 输出 4 | 电流 - 输出（最大值） | 功率（瓦特） | 电压 - 隔离 | 应用 | 特性 | 工作温度 | 效率 | 等级 | 认证 | 安装类型 | 尺寸 / 尺寸 | 供应商设备封装 | 控制特性 | 认证机构 | 标准编号 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
ERM06B110DC DC CONVERTER 12V 75W |
140 | - |
|
数据表 |
ERM75 (75W) | 8-DIP Module | Bulk | Active | Isolated Module | 1 | 66V | 160V | 12V | - | - | - | 6.25A | 75 W | 3 kV | ITE (Commercial), Railway | Remote On/Off, OCP, SCP, UVLO | -40°C ~ 70°C | 91% | - | - | Through Hole | - | - | - | - | |
|
|
ERM03H110DC DC CONVERTER 24V 75W |
139 | - |
|
数据表 |
ERM75 (75W) | 8-DIP Module | Bulk | Active | Isolated Module | 1 | 66V | 110V | 24V | - | - | - | 3.125A | 75 W | 3 kV | ITE (Commercial), Railway | Remote On/Off, OCP, SCP, UVLO | -40°C ~ 70°C | 90% | - | - | Through Hole | - | - | - | - | |
|
|
ERM15A110DC DC CONVERTER 5V 75W |
87 | - |
|
数据表 |
ERM75 (75W) | 8-DIP Module | Bulk | Active | Isolated Module | 1 | 66V | 160V | 5V | - | - | - | 15A | 75 W | 3 kV | ITE (Commercial), Railway | Remote On/Off, OCP, SCP, UVLO | -40°C ~ 70°C | 89% | - | - | Through Hole | - | - | - | - | |
|
70IMX7-24-24-8GDC DC CONVERTER 24V 24V 7.2W |
90 | - |
|
数据表 |
Melcher IMX7 (7W) | 14-DIP Module, 9 Leads | Bulk | Active | Isolated Module, Conformal Coated | 2 | 40V | 121V | 24V | 24V | - | - | 150mA, 150mA | 7.2 W | 2.1 kV | ITE (Commercial), Railway | Remote On/Off, OCP, OTP, OVP, SCP, UVLO | -40°C ~ 85°C | 83% | - | - | Through Hole | - | - | - | - | |
|
|
110IMX7-12-12-8GDC DC CONVERTER 12V 12V 7.2W |
80 | - |
|
数据表 |
Melcher IMX7 (7W) | 14-DIP Module, 9 Leads | Tube | Active | Isolated Module, Conformal Coated | 2 | 60V | 150V | 12V | 12V | - | - | 300mA, 300mA | 7.2 W | 2.5 kV | ITE (Commercial), Railway | Remote On/Off, OCP, OTP, OVP, SCP, UVLO | -40°C ~ 85°C (With Derating) | 83% | - | - | Through Hole | - | - | - | - | |
|
|
SQ48T10050-NBB0GDC DC CONVERTER 5V 50W |
144 | - |
|
数据表 |
SemiQ™ SQ48 (50W) | 8-DIP Module, 1/8 Brick | Bulk | Active | Isolated Module | 1 | 36V | 75V | 5V | - | - | - | 10A | 50 W | 2 kV | ITE (Commercial) | Remote On/Off, OCP, OTP, OVP, UVLO | -40°C ~ 85°C | 87% | - | - | Through Hole | - | Enable, Active Low | - | - | |
|
|
SQ48T10050-NDB0GDC DC CONVERTER 5V 50W |
144 | - |
|
数据表 |
SemiQ™ SQ48 (50W) | 8-DIP Module, 1/8 Brick | Bulk | Active | Isolated Module | 1 | 36V | 75V | 5V | - | - | - | 10A | 50 W | 2 kV | ITE (Commercial) | Remote On/Off, OCP, OTP, OVP, SCP, UVLO | -40°C ~ 85°C (With Derating) | 87% | - | - | Through Hole | Eighth Brick | - | - | - | |
|
|
IQK4N090A112V-1U9-RDC-DC, PCB MOUNT, QUARTER BRICK, |
48 | - |
|
数据表 |
IQK (1008W) | Quarter Brick | Tray | Active | Isolated Module | 1 | 48V | 56V | 11.2V | - | - | - | 90A | 1.008 kW | 707 V | ITE (Commercial) | Adjustable Output, Baseplate, Load Sharing, Remote On/Off, Remote Sense | -40°C ~ 119°C | 96% | - | - | Through Hole | Quarter Brick | Enable, Active Low | CE | 60950-1; 62368-1 | |
|
|
BDQ1300-48S12B-4LIDC DC CONVERTER 12.15V 1300W |
85 | - |
|
数据表 |
BDQ1300 (1300W) | Quarter Brick | Tray | Active | Isolated Module | 1 | 40V | 60V | 12.15V | - | - | - | 107A | 1300 W | 800 V | ITE (Commercial) | Adjustable Output, Baseplate, PMBus™, Remote On/Off | -40°C ~ 85°C | 97.5% | - | - | Through Hole | Quarter Brick | Enable, Active Low | CE, TUV, UL | - | |
|
QSB10048S05DC DC CONVERTER 5V 100W |
32 | - |
|
数据表 |
QSB (100W) | 8-DIP Module | Box | Active | Isolated Module | 1 | 18V | 75V | 5V | - | - | - | 20A | 100 W | 1.5 kV | ITE (Commercial) | Remote On/Off, OCP, OTP, OVP, SCP | -40°C ~ 100°C | 88% | - | - | Through Hole | - | Enable, Active High | - | - | |
|
|
40IMX7-24-24-8GDC DC CONVERTER 24V 24V 7.2W |
90 | - |
|
数据表 |
Melcher IMX7 (7W) | 14-DIP Module, 9 Leads | Bulk | Active | Isolated Module, Conformal Coated | 2 | 16.8V | 75V | 24V | 24V | - | - | 150mA, 150mA | 7.2 W | 2.1 kV | ITE (Commercial), Railway | Remote On/Off, OCP, OTP, OVP, SCP, UVLO | -40°C ~ 85°C (With Derating) | 84% | - | - | Through Hole | - | - | - | - | |
|
|
LTP8800-2IPV#PBF150A DC/DC MODULE REG W/ PMBUS I |
72 | - |
|
数据表 |
- | 22-SMD Module | Tray | Active | Isolated Module | 1 | 45V | 65V | 54V | - | - | - | 135A | 7.3 kW | - | ITE (Commercial) | Adjustable Output, PMBus™ | 0°C ~ 125°C | 89% | - | - | Surface Mount | - | - | - | - | |
|
|
QM48T40033-PBB0GDC DC CONVERTER 3.3V 132W |
179 | - |
|
数据表 |
QmaX™ | 8-DIP Module, 1/4 Brick | Bulk | Active | Isolated Module | 1 | 36V | 75V | 3.3V | - | - | - | 40A | 132 W | 2 kV | ITE (Commercial) | Remote On/Off, OCP, OTP, OVP, SCP, UVLO | -40°C ~ 85°C (With Derating) | 90.5% | - | - | Through Hole | Quarter Brick | - | - | - | |
|
70IMX4-15-8GDC DC CONVERTER 15V 4.2W |
240 | - |
|
数据表 |
Melcher IMX4 (4W) | 24-DIP Module, 13 Leads | Bulk | Active | Isolated Module, Conformal Coated | 1 | 40V | 121V | 15V | - | - | - | 280mA | 4.2 W | 2 kV | ITE (Commercial), Railway | OCP, OTP, OVP, SCP | -40°C ~ 85°C | 80.5% | - | - | Through Hole | - | - | - | - | |
|
IRQ-24/6.25-W80PB-C16V-160V I/P , 24V 150W O/P, POS |
73 | - |
|
数据表 |
IRQ-W80 (150W) | Quarter Brick | Tray | Active | Isolated Module | 1 | 16V | 160V | 24V | - | - | - | 6.25A | 150 W | 4.242 kV | ITE (Commercial), Railway | Adjustable Output, Baseplate, Heat Sink, Remote On/Off, Remote Sense | -40°C ~ 100°C (With Derating) | 89% | - | - | Through Hole | Quarter Brick | Enable, Active High | CE, cURus | 60950-1 | |
|
|
70IMX7-05-8GDC DC CONVERTER 5.1V 7W |
90 | - |
|
数据表 |
Melcher IMX7 (7W) | 14-DIP Module, 9 Leads | Bulk | Active | Isolated Module, Conformal Coated | 1 | 40V | 121V | 5.1V | - | - | - | 1.2A | 7 W | 2 kV | ITE (Commercial), Railway | Remote On/Off, OCP, OTP, OVP, SCP, UVLO | -40°C ~ 85°C | 78% | - | - | Through Hole | - | - | - | - | |
|
|
ERM08B100N100W 1/4 BRICK, NEG-ENABLE, 36-1 |
120 | - |
|
数据表 |
ERM100 (100W) | 8-DIP Module | Tube | Active | Isolated Module | 1 | 36V | 160V | 12V | - | - | - | 8.4A | 100 W | 2 kV | ITE (Commercial), Railway | Adjustable Output, Baseplate, Remote On/Off, Remote Sense | -40°C ~ 85°C (With Derating) | 91% | - | - | Through Hole | - | Enable, Active Low | CE, UKCA | 50155; 62368-1 | |
|
|
ERM04H100N100W 1/4 BRICK, NEG-ENABLE, 36-1 |
120 | - |
|
数据表 |
ERM100 (100W) | 8-DIP Module | Tube | Active | Isolated Module | 1 | 36V | 160V | 24V | - | - | - | 4.2A | 100 W | 2 kV | ITE (Commercial), Railway | Adjustable Output, Baseplate, Remote On/Off, Remote Sense | -40°C ~ 85°C (With Derating) | 89% | - | - | Through Hole | - | Enable, Active Low | CE, UKCA | 50155; 62368-1 | |
|
|
40IMX15-03-8RGDC DC CONVERTER 3.3V 15W |
96 | - |
|
数据表 |
Melcher IMX15 (15W) | 17-DIP Module, 11 Leads | Bulk | Active | Isolated Module, Conformal Coated | 1 | 16.8V | 75V | 3.3V | - | - | - | 4.5A | 15 W | 2.1 kV | ITE (Commercial) | OCP, OTP, OVP, SCP, UVLO | -40°C ~ 85°C | 83% | - | - | Through Hole | - | - | - | - | |
|
|
110IMY15-15-15-8GDC DC CONVERTER 15V 15V 15W |
44 | - |
|
数据表 |
Melcher IMY15 (15W) | 17-DIP Module, 9 Leads | Bulk | Active | Isolated Module, Conformal Coated | 2 | 50V | 150V | 15V | 15V | - | - | 560mA, 560mA | 15 W | 4.2 kV | ITE (Commercial), Railway | OTP, OVP, SCP, UVLO | -40°C ~ 85°C | 87% | - | - | Through Hole | - | - | - | - |
