固定电感器
| 图片 | 厂商型号 | 可用性 | 价格 | 数量 | 数据表 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 电感 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 屏蔽 | 直流电阻 (DCR) | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 额定值 | 工作温度 | 电感频率 - 测试 | 特性 | 安装类型 | 供应商设备封装 | 尺寸 / 尺寸 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
CTC2F-R022JAXL LEADED CONF COATED INDUCTOR |
0 | - |
|
数据表 |
ctc2f | - | Tape & Reel (TR) | Active | - | - | 22 nH | ±5% | - | - | - | 10mOhm | - | 500MHz | - | -55°C ~ 125°C | - | - | Through Hole | - | - | - |
|
CTPCI7045F-101MSMD SHLDED POWER INDUCTOR |
0 | - |
|
数据表 |
CTPCI7045F | Nonstandard | Tape & Reel (TR) | Active | - | - | 100 µH | ±20% | 1.05 A | 800mA | Shielded | 312mOhm Max | - | - | - | -40°C ~ 105°C | 100 kHz | - | Surface Mount | - | 0.291" L x 0.276" W (7.40mm x 7.00mm) | 0.189" (4.80mm) |
|
CTLV5020SF-3R9M3.9UH SMD POWER INDUCTOR |
0 | - |
|
数据表 |
CTLV5020SF | 2020 (5050 Metric) | Tape & Reel (TR) | Active | - | - | 3.9 µH | ±20% | 2.34 A | 2.61A | Shielded | 53mOhm | - | - | - | -55°C ~ 125°C | 100 kHz | - | Surface Mount | 2020 | 0.197" L x 0.197" W (5.00mm x 5.00mm) | 0.087" (2.20mm) |
|
CTLL2012SF-47NJSMD HIGH FREQCER MULTIL INDUCTOR |
0 | - |
|
数据表 |
CTLL2012SF | 0805 (2012 Metric) | Tape & Reel (TR) | Active | Multilayer | Ceramic | 47 nH | ±5% | 300 mA | - | Unshielded | 700mOhm Max | 18 @ 100MHz | 900MHz | - | -55°C ~ 125°C | 100 MHz | - | Surface Mount | 0805 | 0.079" L x 0.049" W (2.00mm x 1.25mm) | 0.041" (1.05mm) |
|
CTLVC6028F-101M100UH SMD POWER INDUCTOR |
0 | - |
|
数据表 |
CTLVC6028F | 2424 (6060 Metric) | Tape & Reel (TR) | Active | - | - | 100 µH | ±20% | 720 mA | 730mA | Shielded | 600mOhm | - | - | - | -55°C ~ 125°C | 100 kHz | - | Surface Mount | 2424 | 0.236" L x 0.236" W (6.00mm x 6.00mm) | 0.118" (3.00mm) |
|
CTH8HCF-101K100UH AXIAL PWR LINE INDUCTOR |
0 | - |
|
数据表 |
CTH8HCF | Axial | Tape & Reel (TR) | Active | - | - | 100 µH | ±10% | 3.8 A | 5.7A | Unshielded | 55mOhm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Axial | 0.550" Dia x 1.000" L (13.97mm x 25.40mm) | - |
|
CTDT3316PF-22322UH SMD SHIELDED POWR INDUCTOR |
0 | - |
|
数据表 |
CTDT3316PF | Nonstandard | Tape & Reel (TR) | Active | - | - | 22 µH | ±20% | 1.5 A | - | Shielded | 84mOhm Max | - | 22MHz | - | -40°C ~ 85°C | 100 kHz | - | Surface Mount | - | 0.510" L x 0.370" W (12.95mm x 9.40mm) | 0.200" (5.08mm) |
|
|
CTDT3316PF-47347UH SMD SHIELDED POWR INDUCTOR |
0 | - |
|
数据表 |
CTDT3316PF | Nonstandard | Tape & Reel (TR) | Active | - | - | 47 µH | ±20% | 1 A | - | Shielded | 110mOhm Max | - | 16MHz | - | -40°C ~ 85°C | 100 kHz | - | Surface Mount | - | 0.510" L x 0.370" W (12.95mm x 9.40mm) | 0.200" (5.08mm) |
|
CTXAL5030F-1R0MHIGH CURRENT SMD POWER INDUCTOR |
0 | - |
|
数据表 |
CTXAL5030F | Nonstandard | Tape & Reel (TR) | Active | - | - | 1 µH | ±20% | 12.2 A | 14.3A | Shielded | 7.6mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.217" L x 0.209" W (5.50mm x 5.30mm) | 0.122" (3.10mm) |
|
CT622LYF-471JRADIAL LEADED FIXED INDUCTOR |
0 | - |
|
数据表 |
ct622lyf | - | Bulk | Active | - | - | 470 µH | ±5% | - | - | - | 1.1Ohm | - | 1.9MHz | - | -55°C ~ 125°C | - | - | Through Hole | - | - | - |
|
|
CTH8HCF-333K33000UH AXIAL PWR LINE INDUCTOR |
0 | - |
|
数据表 |
CTH8HCF | Axial | Tape & Reel (TR) | Active | - | - | 33 mH | ±10% | 160 mA | 330mA | Unshielded | 21Ohm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Axial | 0.550" Dia x 1.000" L (13.97mm x 25.40mm) | - |
|
CTH8F-822K8200UH AXIAL PWR LINE INDUCTOR |
0 | - |
|
数据表 |
CTH8F | Axial | Bulk | Active | - | - | 8.2 mH | ±10% | 250 mA | 293mA | Unshielded | 6.32Ohm Max | - | 300kHz | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Axial | 0.469" Dia x 0.921" L (11.90mm x 23.40mm) | - |
|
CM32252R2KSBWOUND CHIP INDUCTOR,3225, 2.20UH |
0 | - |
|
- |
CM3225-S | 1210 (3225 Metric) | Tape & Reel (TR) | Active | Wirewound | Ferrite | 2.2 µH | ±10% | 320 mA | - | Unshielded | 1Ohm Max | 30 @ 7.96MHz | 100MHz | - | -40°C ~ 125°C | 7.96 MHz | - | Surface Mount | 1210 | 0.126" L x 0.098" W (3.20mm x 2.50mm) | 0.087" (2.20mm) |
|
CM4532470KSBWOUND CHIP INDUCTOR,4532, 47.00U |
0 | - |
|
- |
CM4532-S | 1812 (4532 Metric) | Tape & Reel (TR) | Active | Wirewound | Ferrite | 47 µH | ±10% | 140 mA | - | Unshielded | 5Ohm Max | 50 @ 2.52MHz | 10.5MHz | - | -40°C ~ 125°C | 2.52 MHz | - | Surface Mount | 1812 | 0.177" L x 0.126" W (4.50mm x 3.20mm) | 0.134" (3.40mm) |
|
PC0504-470K-RC47UH 10% POWER CHIP INDUCTOR |
0 | - |
|
数据表 |
- | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 47 µH | ±10% | 720 mA | - | Unshielded | 370mOhm Max | - | - | - | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.228" L x 0.205" W (5.80mm x 5.20mm) | 0.189" (4.80mm) |
|
|
PC0504-220K-RC22UH 10% POWER CHIP INDUCTOR |
0 | - |
|
数据表 |
- | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 22 µH | ±10% | 1.11 A | - | Unshielded | 180mOhm Max | - | - | - | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.228" L x 0.205" W (5.80mm x 5.20mm) | 0.189" (4.80mm) |
|
|
PC0504-331M-RC330UH 20% POWER CHIP INDUCTOR |
0 | - |
|
数据表 |
- | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 330 µH | ±20% | 280 mA | - | Unshielded | 1.7Ohm Max | - | - | - | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.228" L x 0.205" W (5.80mm x 5.20mm) | 0.189" (4.80mm) |
|
SMAC60-R30L-RC300NH 15% SMD AIR COIL INDUCTOR |
0 | - |
|
数据表 |
- | Nonstandard | Tray | Active | Wirewound | Air | 300 nH | ±15% | 3.5 A | - | Unshielded | 49mOhm Max | 1 @ 200MHz | - | - | -40°C ~ 125°C | 200 MHz | - | Surface Mount | - | 0.465" L x 0.190" W (11.80mm x 4.83mm) | 0.140" (3.55mm) |
|
ALA0410-102KAXIAL LEAD INDUCTORS |
0 | - |
|
- |
- | - | Bulk | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
ALC0410-101KAXIAL LEAD INDUCTORS |
0 | - |
|
- |
- | - | Bulk | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
